DYNACORD CMS 1600-3 ?

DYNACORD The CMS 1600-3 ? is a professional compact mixing system designed for concert PAs, mobile PA systems and stationary installations where multiple inputs and complete processing are required in one unit. It has 16 input channels - 12 Mic/Line and 4 Mic/Stereo-Line, with high-quality low-noise discrete microphone preamps and +48 V phantom power, switchable in groups. Six auxiliary buses provide flexible control of monitors and effects, with two switchable between Pre and Post Fader. The two independent stereo effects processors each offer 100 factory and 20 user presets, including reverb, echo, delay, chorus and flanger, with a TAP function for precise delay time setting. The built-in 4x4 USB audio interface supports 4 simultaneous recording and 4 playback channels at up to 24-bit/96 kHz, and the MIDI interface allows for effects control and integration with external equipment. The 11-band stereo graphic EQ can be routed to a Master or Monitor signal. The CMS 1600-3 ? uses high-quality ALPS faders and potentiometers, an OLED display and balanced XLR outputs, and the housing is also designed for easy transport. (Dynacord)

Technical characteristics

• Type: professional compact mixing system
• Channels: 16
• Configuration: 12 x Mic/Line + 4 x Mic/Stereo-Line
• Auxiliary buses: 6 – 2 Pre, 2 Post, 2 Pre/Post
• Microphone preamplifiers: discrete, low noise
• MIC Gain: 0 to +60 dB / +10 to +60 dB
• Frequency response: 15 Hz – 70 kHz (-3 dB)
• THD: <0.005%
• Low-Cut: 80 Hz, 18 dB/oct.
• Voice Filter: switchable
• Feedback Filter: 70 Hz - 7 kHz, Notch
• Master EQ: 11-band stereo, ±10 dB
• Effect processors: 2 x stereo, 24/48-bit
• Effects: 100 factory + 20 user presets per processor
• Tap Delay: yes
• Effects Control: MIDI / Footswitch
• USB audio interface: 4 inputs / 4 outputs
• USB resolution: 24-bit
• USB frequencies: 44.1 / 48 / 88.2 / 96 kHz
• USB: USB 2.0 Type-B
• MIDI: 5-pin DIN In/Out
• Phantom power: +48 V
• Display: 128 x 64 pixel OLED
• Power supply: 100–240 V AC, 50–60 Hz
• Consumption: 50 W / 55 W with lamp
• Dimensions: 663.5 x 155 x 498.5 mm
• Weight: 12 kg
• Optional cover: DC-LID1600
• Origin: Germany

FAQ

How many channels are there? DYNACORD CMS 1600-3 ?
It has 16 input channels – 12 Mic/Line and 4 Mic/Stereo-Line.

Does it have a built-in USB audio interface?
Yes. The 4x4 USB interface enables simultaneous 4-channel recording and 4-channel playback at up to 24-bit/96 kHz.

How much effect does the processor have?
Two independent stereo digital effects processors, each with 100 factory and 20 user presets.

Is there an equalizer for the main signal?
Yes. The CMS 1600-3 ? features an 11-band stereo graphic equalizer that can be routed to a Master or Monitor signal.

Is it suitable for professional concert sound?
Yes. The design, 16 input channels, six auxiliary buses, digital effects and balanced outputs are designed for professional live applications and stationary installations.
